Cannondale Synapse 1
Details
Road Reimagined
Roll smooth, roll fast, roll confident. Wherever the road takes you, roll with Synapse – our most comfortable, all-around, up-for-anything, pure road machine.
What it's for
Enjoyable road riding with comfort, speed, and finesse.
Where it thrives
The open road, up & down hills, rough pavement
What it's built for
Comfort, handling, going long
Highlights
- Lightweight SmartForm C2 Alloy Frame w/ full carbon fork
- Shimano's legendary 105 12-speed group - incredible performance value
- Shimano 105 hydraulic disc brakes for smooth, controllable braking
- Light, durable DT Swiss R470 wheels with 700x30c Vittoria tires
| Frame Size | 44cm | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Wheel Size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Seat Tube Length (cm) | 40 | 42.2 | 44.3 | 48 | 52 | 55 | 59 |
| Top Tube Horizontal (cm) | 52.1 | 53.3 | 54.4 | 55.5 | 56.7 | 58 | 59.8 |
| Head Tube Angle (°) | 70.2° | 70.8° | 71.0° | 71.9° | 72.0° | 72.0° | 72.0° |
| Seat Tube Angle Effective (°) | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° | 73.0° |
| Standover (cm) | 68.1 | 70.2 | 72.3 | 75.3 | 78.4 | 81 | 84.5 |
| Head Tube Length (cm) | 9.6 | 11.5 | 14 | 16 | 18.1 | 20.5 | 23.6 |
| Wheelbase (cm) | 98.5 | 99.3 | 100.6 | 101 | 102.1 | 103.5 | 105.4 |
| Front Center (cm) | 58.4 | 59.1 | 60.2 | 60.6 | 61.7 | 63 | 64.9 |
| Chain Stay Length (cm) | 41.5 | 41.5 | 41.5 | 41.5 | 41.5 | 41.5 | 41.5 |
| Bottom Bracket Drop (cm) | 8 | 8 | 7.5 | 7.3 | 7.3 | 7 | 7 |
| Bottom Bracket Height (cm) | 26.3 | 26.3 | 26.8 | 27 | 27 | 27.3 | 27.3 |
| Fork Rake (cm) | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 |
| Trail (cm) | 6.5 | 6.1 | 6 | 5.4 | 5.4 | 5.4 | 5.4 |
| Stack (cm) | 51 | 53 | 55 | 57 | 59 | 61 | 64 |
| Reach (cm) | 36.5 | 37.1 | 37.6 | 38.1 | 38.7 | 39.3 | 40.2 |
| Frame | Rider Height (cm) | Rider Height (in) |
|---|---|---|
| 44cm | 152 - 162 | 5'0" - 5'4" |
| 48cm | 157 - 167 | 5'2" - 5'6" |
| 51cm | 165 - 175 | 5'5" - 5'9" |
| 54cm | 170 - 180 | 5'7" - 5'11" |
| 56cm | 175 - 185 | 5'9" - 6'1" |
| 58cm | 182 - 193 | 6'0" - 6'4" |
| 61cm | 190 - 203 | 6'3" - 6'8" |
WARNING - INGESTION HAZARD: This product contains a button cell or coin battery. DEATH or serious injury can occur if ingested. A swallowed button cell or coin battery can cause Internal Chemical Burns in as little as 2 hours. KEEP new and used batteries OUT OF REACH OF CHILDREN. Seek immediate medical attention if a battery is suspected to be swallowed or inserted inside any part of the body.
Specs are subject to change without notice.
Specs
| Fork | Synapse Carbon, integrated crown race, 12x100mm thru-axle, internal routing, flat mount brake, fender mounts |
|---|---|
| Hubs |
Front: Formula CL-712, 12x100mm centerlock Rear: Formula RXC-400, 12x142mm centerlock |
| Rims | DT Swiss R470 DB, 28h |
| Stem | Cannondale 3, 6061 Alloy, 31.8, 7° |
| Chain | Shimano 105 7100, 12-speed |
| Frame | Lightweight SmartForm C2 Alloy, SmartSense compatible, BSA threaded BB, internal cable routing, flat mount, 142x12 thru-axle, hidden rack/fender mounts |
| Tires | Zaffiro Pro Bright Black Reflective, 700x30c |
| Brakes | Shimano 105 7170 hydraulic disc, 160/160 RT70 rotors |
| Saddle | Fizik Aliante Delta, S-alloy rails |
| Spokes | Stainless Steel, 14g |
| Headset | Integrated, 1-1/8" - 1-1/4" |
| Crankset | Shimano RS520, 50/34 |
| Seatpost | Cannondale 3, 6061 Alloy, 27.2x350mm |
| Shifters | Shimano 105 7100, 12-speed |
| Handlebars | Cannondale 3, 6061 alloy, Compact |
| Tape/Grips | Cannondale Bar Tape, 3.5mm |
| Brake Levers | Shimano 105 7100 hydraulic disc |
| Bottom Bracket | Shimano BB-RS500, BSA |
| Rear Derailleur | Shimano 105 7100, 12-speed |
| Front Derailleur | Shimano 105 7100, braze-on |
| Accessories & Extras | Trainer axle end caps |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Black / 44cm / 700c | 884603950661 | C12503U2044 | |
| Black / 56cm / 700c | 884603950708 | C12503U2056 | 210000004256 |
| Black / 58cm / 700c | 884603950715 | C12503U2058 | |
| Black / 61cm / 700c | 884603950722 | C12503U2061 | |
| Rally Red / 44cm / 700c | 884603950593 | C12503U1044 | |
| Rally Red / 58cm / 700c | 884603950647 | C12503U1058 | |
| Rally Red / 51cm / 700c | 884603950616 | C12503U1051 | |
| Rally Red / 61cm / 700c | 884603950654 | C12503U1061 | |
| Black / 51cm / 700c | 884603950685 | C12503U2051 | |
| Rally Red / 56cm / 700c | 884603950630 | C12503U1056 | 210000004254 |
| Black / 48cm / 700c | 884603950678 | C12503U2048 | |
| Rally Red / 54cm / 700c | 884603950623 | C12503U1054 | 210000004253 |
| Rally Red / 48cm / 700c | 884603950609 | C12503U1048 | 210000005111 |
| Black / 54cm / 700c | 884603950692 | C12503U2054 | 210000004255 |
| Cashmere / 44cm / 700c | 196870085923 | C12503U3044 | |
| Cashmere / 48cm / 700c | 196870085930 | C12503U3048 | |
| Cashmere / 51cm / 700c | 196870085947 | C12503U3051 | |
| Cashmere / 54cm / 700c | 196870085954 | C12503U3054 | |
| Cashmere / 56cm / 700c | 196870085961 | C12503U3056 | |
| Cashmere / 58cm / 700c | 196870085978 | C12503U3058 | |
| Cashmere / 61cm / 700c | 196870085985 | C12503U3061 |
